3S 5992S 57" x 1.66" O.D. 18 AWG Galvanized Steel Satellite Dish Swaged Ground Pole Mast
Ideal as a DISH500 and DIRECTV Dish Antenna Mast (will NOT work for DIRECTVs SL3/5) for Ground or Wall mount Installation (Mount Not Included). Sturdy One Piece ( Actual Length 57") that Fits a Variety of Mounts for Flexibility In Antenna Mounting and Height Clearance.
This Mast can be utilized for HDTV Off-Air Antenna installation as well, providing the clamp on the antenna can accomodate a 1.66 inch DIA 18 AWG mast pipe. DISH500 and DIRECTV Antennas can be mounted on the ground with the proper poured concrete foundation. When installing on the side of a premise or structure (ie House), be sure and afford yourself 2 feet minimum, up to 1/3 of the overall mast length between the two wall mounts you will utilize. Depending on the size of the Satellite Dish or Antenna, the Torque applied from wind load through cantilever to these mounts can be significant.
Selecting the proper antenna mast pipe is crucial. Depending on the size of your antenna, it's EPA, weight and height all play a factor in selecting a supportive pole. When planning, it's best to have all the information you can get like outside diameter of your attaching method, the clearance of gutters, siding or other obstacles in the path of your erecting a mast or tower.
Here you will find standard straight pipe in 5' foot and 10' foot lengths. You can also find those same pipes with a special end called a swag. A swaged ended pipe allows you to attach several lengths of pipe together.
|Swaged End||Straight End|
When selecting a pipe you will need to know the length, OD (outside diameter), the AWG 16 or 18 (the smaller the number the thicker the steel) and weather you'll need any swaged ended pieces. You'll then need to select the proper mounting such as wall, roof or maybe a tripod.
