3 Star Inc 17C01 Ceramic Insulator up to 5/16" Strand Down Guy

3 Star Inc 17A01 Ceramic Strain Insulator for up to 3/16" EHS Down Guy
The 17A01 is a Ceramic Strain Insulator for 3/16" inch strand. It has 5/16" holes for Clevis and Preformed Dead-end Termination Down Guy Segments with a 2-5/16" length and a diameter of 1-3/8". Guy Line Insulators are used to isolate RF (Radio Frequency) Electrical Conductivity and Passive Re-Transmission or Intermodulation by dividing guy wires into non-resonant sections. This prevents the guy lines from altering an Antenna's Radiation Pattern due to near-field interaction and for Ghosting Resonate Towers to Prevent Shadow Zones of other Transmitter Facilities Broadcast Coverage Area.

3 Star Inc 17B01 Ceramic Strain Insulator with 10,000 lbs. Rating for up to 1/4" EHS Down Guy
The 17B01 is a Ceramic Strain Insulator rated at 10,000 lbs. Ultimate Strength with a 5,000 lbs. Working Load Limit (WLL) for up to 1/4" inch strand. It has 5/8" holes for Clevis and Preformed Dead-end Termination Down Guy Segments with a 3-1/2" length and a diameter of 2-1/2". Guy Line Insulators are used to isolate RF (Radio Frequency) Electrical Conductivity and Passive Re-Transmission or Intermodulation by dividing guy wires into non-resonant sections. This prevents the guy lines from altering an Antenna's Radiation Pattern due to near-field interaction and for Ghosting Resonate Towers to Prevent Shadow Zones of other Transmitter Facilities Broadcast Coverage Area.

MacLean GCC15-12R Guy Strain Insulator Clevis to Clevis-w-Roller 15,000 lbs
Fiberglass Rod with Iron Galvanized Fittings End Fittings:
Clevis - Clevis w/Roller
Rod Size - in - 5/8
Rod Length - in - 12.00
Overall Length - in - 22.25
Flashover Dry/Wet - kV - 140/70
Strength - lb - 15,000
Roller Groove Radius: 5/16"

Maclean J732 1/2" inch Clevis for Heavy Strain Porcelain Guy Insulator L506
The J732 1/2" inch is a Hot Dip Galvanized Clevis featuring a Curved Bolt with Anco Locknuts for use with the Heavy Strain Porcelain Guy Insulator L506 series, as a component for Heavy Strain Insulated Down Guys in OSP Pole Lines and Guyed Communications Towers.
